- ADC-9005BAT Rechargeable Battery for ADView 2 Modular Diagnostic Station
-
The ADC Rechargeable Battery for ADView 2 Modular Diagnostic Station (9005BAT) uses lithium-ion power for longer-lasting battery life and a lighter weight, and can be used to replace the battery on the ADView 2 Modular Diagnostic Station
-
Power;Input: 100-240 VAC @ 1.5A max, 50-60 Hz–Output: +9VDC @ 5A IEC 320 type input connector
- Battery Type: 7.2v, 6600mAh Internal Lithium-Ion battery
- Battery Run Time (full charge): ~20 hrs* / 200 BP cycles
- Unit with BP, Temp, SpO2, Wi-Fi, barcode scanner
Features
- Chemistry
Utilizes Lithium-Ion technology, which offers a superior energy-to-weight ratio and a longer overall service life compared to traditional nickel-based batteries. - Capacity
Features a 6600 mAh capacity, allowing the diagnostic station to perform approximately 200 full blood pressure cycles on a single charge. - Compatibility
Engineered specifically for the ADView 2 series, ensuring precise voltage regulation for the monitor’s NIBP, SpO2, and temperature modules. - Efficiency
Designed for rapid charging, typically reaching a full charge in approximately 6 hours when the unit is connected to an AC power source. - Reliability
Provides a consistent 7.2V output, ensuring that the diagnostic station maintains its clinical accuracy even as the battery level begins to deplete. - Design
Features a user-accessible housing, allowing medical staff to easily replace the battery in the field without requiring specialized tools or service.
Specifications
- Type Battery
- Chemistry Lithium-Ion
- Voltage 7.2V
- Capacity 6600 mAh
- Device ADView 2
- Weight 0.9 lb
- Warranty 1 Year
